SKU: tecmen-welding-helmet


The Tecmen welding helmet Freflow V1 is a powered air purifying respirator (PAPR) system that will deliver filtered air to the operator for up to 9 hours.

This auto darkening helmet is suitable for welding, cutting and grinding tasks and features a 97mm x 62mm viewing area, 4 arc sensors and 1/1/1/1 optical classification.
The complete air blower unit, including lithium-ion battery, weighs 1.2kg and is fitted around the waist by an adjustable belt.



PAPR Specifications:

  • Airflow Rate (lpm): Low 170 / High 210
  • Battery: Rechargeable Li-ion
  • Battery Charge: 1 hr standard / 2 hr extended
  • Battery Life: 550 charges
  • Filter Efficiency: 99.97%
  • Alarms: Visible, Audible, Vibrate
  • Weight 1.2kg
  • Standard: EN12941 TH2, NIOSH 42 CFR84 AS/NZS 1716

ADF800S Helmet Specifications:

  • Optical Class: 1/1/1/1
  • Viewing Area: 97 x 62mm
  • Cartridge: 133 x 114 x 9mm
  • Arc Sensor: 4
  • Light/Dark State: DIN3.5 / DIN 5-8 / DIN 9-13
  • Shade Control: Internal, Variable Shade
  • Power On/Off: Fully automatic
  • Switching Time: 1/25,000 s light to dark
  • Delay (Dark to Light): 0.1 ~ 1.0s by dial control
  • Low Amperage TIG rated (AC – DC): ≥ 2 amps

Replacement Parts:
